Hello

Long time no write, again. Shame on me. Anyway…

Recently I had the opportunity to work for INCAS, which is a research institute for aerospace vehicles. They bought a cluster, a Super Micro chassis to be more specific, and needed a sysadmin to put it alltogether: install the operating systems, configure the networking, storage and all the necessary things. After 2 versions, I finally understood what they needed: they have codes written by themselves in Fortran using Linux development tools and they also have commercial Windows applications. So basically they needed both the operating systems on the nodes. After I tried to use virtualization tools to configure an easy mode to switch between them, I reached a scalability issue: KVM supports only 2 cores (tested on RHEL5) and ESXi 5 is also limited to 8 cpus and the network latency is quite high.

So the conclusion was: dual boot. So far so good but there are 20 blade servers to dual boot. The Super Micro chassis has indeed a great tool for remote management but it’s not funny to wait for every server to POST and then select witch OS to boot.

After I searched the web, I found that grub supports FAT32 file system witch means that the /boot partition can be written on a vfat partition. This was exactly what I needed because the FAT32 file system can be written from both operating systems.

To implement this all you have to do is this (for clean install):

1. create a partition for /boot and write an ext3/4 file system to it (the Scientific Linux 6.1 Installer won’t let you install /boot on a vfat file system)
2. create the rest of the partitions: / and swap
3. install the Linux operating system

After the server is up and running do the following:

1. copy the /boot to a temporary folder: mkdir /root/boot-tmp; cp -ar /boot /root/boot-tmp
2. umount /boot
3. mkfs.vfat /dev/sda3 (the /boot partition)
4. update the partition type (c is for FAT32): fdisk /dev/sda -> t 3 -> c
5. update /etc/fstab (if you are using UUID then the blkid will tell you the new UUID, else just replace it with the /dev/sda3) and don’t forget to update the file system from ext3/4 to vfat
6. mount /boot ; cp -ar /root/boot-tmp /boot
7. reboot the system and cross your fingers

Almost done. To automate the switch between Windows and Linux you need to install Cygwin on Windows to be able to run a SSH server on Windows and to have a grub.conf configuration file on the management node: if you need Linux the update the default entry in grub.conf to point to the Linux OS, if you want Windows the do the same for Windows. After the grub.conf is correct (usually the root partition is specified by its UUID, which is different from server to server, just replace that with the actual partition name), you just simply scp it to the server and then reboot. It should boot to the operating system where the default entry in grub.conf points to. This was done using grub 1 but should be the quite the same on grub 2.

Good luck.

Vineri m-am gandit sa dau o tura la o poza si ca tot urma sa ies cu Roxana in oras, m-am gandit sa mergem in gradina botanica din Bucuresti pentru a trage niste fotografii de toamna. La munte ar fi fost mai frumos, dar a iesit ceva si aici. Zis si facut: ne-am intalnit la metrou la Politehnica si am luat-o pe jos spre intrarea principala de la Palatul Controceni. Intrarea 2lei studenti, 5lei adulti, mi se pare foarte putin comparativ cu suprafata care trebuie intretinuta dar probabil ca au fonduri din alte parti. Am constatat ca locatia este folosita si ca parc de distractii pentru cei mici: parinti, bunici cu copiii in parc la plimbare. Am mers la aleea cu castani (in partea dreapta a gradinii) cu gandul sa pozez aceea alee iar apoi am dat o tura de gradina sa vedem ce mai gasim de pozat dar s-a intunesc intre timp si am plecat. Aveti mai jos ce a iesit.

Hello

This year we wanted to bring something new to out course platform at the Faculty of Automatic control and Computer science. The first thing that came up was the Instant Messaging feature that is into Moodle. With this feature a student can receive notifications from the course site in real time (most of them). If the user is offline it will receive the messages when at the first login. We what to create a chat room for each course where students to interact and to ask question about their assignments.

So we took one piece Jabber Server – Openfire – and one piece Moodle 2.1 instance and implemented the idea. It works quite well especially because we use a centralized authentication server (LDAP) and the student will use the same account on Moodle site and on the Instant Messaging service.

Openfire is quite a cool Jabber Server. It is written in Java and has a web administration frontend from where you can change the server settings, add users, monitor the server and so on. The setup was smooth. The only thing that might be improved is that it only supports one type of authentication system per instance: you cannot combine manual users with ldap accounts. Is or the one or the other. The lack for a cli tool to administer the service is also a minus, but you can hack the database, most of the settings being stored there.

As a client Pidgin rule. It is light im client that can be used will almost all the im providers out there.

We like to give it a try. You have below a print screen of a pidgin xmpp account setup. The username is the one you are using for the cs.curs.pub.ro.

Hello

Today I installed the latest Debian release, version 6. I was a Debian 5 user when was up to date at the time, then I switched to Ubuntu because it provides updated packages. What I like about Debian is the simplicity: Ubuntu has become to automated. I prefer a clean linux distribution.

I work mostly on remote systems via ssh. I wondered why I have to wait so long for a login prompt and the answer came from an old ubuntu forum [1]. It was the /etc/nsswitch.conf file that had to be modified not to use the avahi multicast dns service. The hosts line should look like this: hosts: files dns.

[1] http://ubuntuforums.org/showthread.php?t=574818

Well, now that IANA is out of IPv4 addresses it’s time to consider migrating the infrastructure to IPv6 to have a dual stack or at least try to test the network devices if they are IPv6 ready.

Lately we received a /56 prefix for NCIT Cluster at out Faculty. We were excited at the beginning, but after we tried to deploy an IPv6 network thing weren’t that excited. Servers where ok, the linux operating system has a good IPv6 implementation, the problem was at the network equipment: Cisco routers.

The main router is a Cisco 4948 layer 3 switch which I think is has a buggy IPv6 stack. From the router I am able to ping ipv6.google.com but only if the IPv6 network is directly connected. If I add a second router, basically there are 2 routers in cascade, no mater what routes I add on the Cisco the packets aren’t routed behind the Cisco 4948 to the second router. If the networks were added as vlan interfaces directly on the main router, the routing processes goes smooth, but when it comes to static routing, the routing table is just a table.

So looks like our old Cisco 4948 router is not fully capable of doing real IPv6 work. May be a firmware upgrade will fix that, how knows because the update isn’t that new.

UPDATE:

In cele din urma a functionat. Am refacut toate configuratiile de pe echipament legate de IPv6 si acum merge rutarea fara probleme.

And yes, it will happen one day and that day is not very far.

I went this morring to a rlug workshop about IPv6. The workshop took place in EG106 at UPB. The trainers were employments at a romanian ISP. They played a little with IPv6 to provide the ftp.lug.ro mirror over IPv6. In Romania ISP-providers don’t provide yet IPv6 connectivity but they managed to get a prefix from IANA and to put up ftpv6.lug.ro.

At the workshop the admins put up an 6to4 tunnel and in the lab there were like 14-16 computers with public IPv6 address. It was interesting how the 6to4 thing works: basicaly you can have IPv6 everywere. We tried a couple of websites that are IPv6 enabled and ya we surfed the google page over IPv6 (ipv6.google.com).

Before I went to the workshop – to do my homework – I configured a gogo6 tunnel on my server to play a little with IPv6. With gogo6 you will pe able to have public IPv6 address witch are tunnelled over IPv4 to gogo6 server end then unencapsulated till the IPv6 destination is reached, over the small IPv6 internet.

When the exams session will be over I will try and implement an 6to4 tunnel.

From know on, as long as the tunnel will be up, the server will be recheable using the hostname ipv6.doraz.ro for those currios to test your IPv6 infrastructure.

Hello

I have to do a large deployment of VMWare Server 2 infrastructure in our cluster at school to run about 1000 vm’s for a project. With out current infrastructure we are able to run only about 700 vm’s but it’s enought.

The instalation of the VMWare Server 2 service was easy, i just had to configure the cfagent to do it for me. The instalation was done on Scientific Linux 5.5, so the modules were allready compiled. The ugly part was running vmware-config.pl all nodes.

So I started to search the web to find an elegant solution to my problem. The were sugestions on running vmware-config.pl with a response file as input but it didn’t work (vmware-config.pl < responses). A friend sugested me to try using expect scripts to automate the task. I googled a little and found some good examples on how to use expect. Expect is a tcl toolkit designed to automate wizards witch usualy requires human interaction.

After some try-catch demos I made this tcl script that reads a response file and with the help of expect the vmware configure wizard is run without human interaction. So I configured cfagent to run this script for me all nodes. You may need to adapt the response file to your needs. I had to tweek the vmware-config.pl script not to display the licence, just the yes/no question.

Info:

• http://www.tcl.tk/man/tcl/tutorial/tcltutorial.html
• http://oreilly.com/catalog/expect/chapter/ch03.html

Script:

#!/usr/bin/expect --

set response_file "/root/bin/responses.txt"
set match [list]
set responses  [list]
set program "/root/bin/vmware-config.pl"

#exp_internal 1

set infile [open $response_file r]
while { [gets $infile line] >= 0 } {
	set tmp [split $line "|"]
	lappend match [lindex $tmp 0]
	lappend responses [lindex $tmp 1]
}
close $infile

set n [llength $match]

#exec yum -y erase VMware-server.x86_64
#exec rm -rf /etc/vmware
#exec yum -y install VMware-server.x86_64

set timeout 60
spawn $program

for {set i 0} {$i < $n} {incr i} {
	set item [lindex $match $i]
	set resp [lindex $responses $i]
	puts "$item -> $resp"
	expect -regex ".*$item.*"
	send "$resp\n"
	sleep 1
}

expect eof

Reponse file:

Press enter to display it|
Do you accept|yes
Do you want networking for your virtual machines|yes
Configuring a bridged network for vmnet0|br0
Which one do you want to bridge to vmnet0|eth0
Do you wish to configure another bridged network|yes
Configuring a bridged network for vmnet2|br1
Which one do you want to bridge to vmnet2|eth1
Do you wish to configure another bridged network|no
Do you want to be able to use NAT networking in your virtual machines|no
Do you want to be able to use host-only networking in your virtual machines|no
Please specify a port for remote connections to use|
Please specify a port for standard http connections to use|
Please specify a port for secure http \(https\) connections to use|
specify a different administrator|yes
Please specify the user whom you wish to be the VMware Server administrator|vmadmin
In which directory do you want to keep your virtual machine files|
what you want|yes
XXXXX-XXXXX-XXXXX-XXXXX|SERIAL
In which directory do you want to install the VMware VIX API binary files|
In which directory do you want to install the VMware VIX API library files|
Is this what you want|
In which directory do you want to install the VMware VIX API document pages|
Is this what you want|

Well, finaly I managed to get a release of NetAdmin so that you can see what can do and maybe sugest some improvements. It is a pre-alfa release so it has things more or less implemented but is usable. The link to the project is https://netadmin.doraz.ro. You need to authenticate with user demo and password d3m0netadmin (d3m0 with zerro) and then create your own account for NetAdmin. The username will be your email address filled in the account creation form.

Due to development phase, I realised that the design I chose isn’t very good. This version will be developed to a certain point to achieve its usability while a new design will be developed and implementend. When the next version will be released, data will be migrated.

Sorry for inconvinience because the site’s structure has been changed a little. First it looked ok with the Pages there but as far as you can’t post to pages I had to change it. So you will see posts that were written long time ago on the front page now and the tabs near home button gonne. Instead of pages there are now categories.

Thanks for understanding.
